High Frequency Welding Equipment

The High Frequency welding equipment is one of our main products.  From 60kw up to 1200kw to match different tube mill.

Multiple and sensitive protection ensures the safe operation of the high frequency welding equipment.

l  Over-current Protection: short circuit of induction coil or mis-operation may cause over-current, when exceeds the set value, protection occurs immediately.

l  Open Circuit: Mis-operation or induction coil is open circuit, protection occurs immediately.

l  Wrong phases: Three phase sequence wrong, protection occurs immediately. L5 of MUCK board is on.

l  Temperature protection: the temperature of the vibration device on the moulding board is once higher than 60 centigrade, protection occurs immediately.

l  Water-lack protection: When the water-pressure is not high enough or lower than the preset value, protection occurs immediately.

l  Water-temperature: The water temperature of cycling water is higher than the temperature rating, protection occurs immediately.

l  Working power supply protection: 24V switching power supply is not normal, protection occurs immediately.

l  Power board protection: The supply voltage is lower than 15V, water temperature is too high, MOSFET tube damage, impulse loss, protection occurs immediately.

l  Frequency protection: Bad output leg insulation, arcing, protection occurs immediately.

l  Phase lock protection: Tank capacitor damage, bad output leg insulation, protection occurs immediately.

1. Field Commissioning

The seller would send one technical engineer to the equipment worksite to commissioning the Induction HF Welding Machine.

2. One Year Warranty Period

12 months from the date of the equipment is qualified to be commissioned by the Seller’s technician at the Buyer’s site. Or 18 months from the date of the equipment leaves the factory of the seller, which first comes, first serves

3.Sufficient spare parts inventory

4. Provide 7 x 24 hours full response service.

5. life-long paid service, and spare parts
