ERW Pipe Production Line

Product Name: ERW Pipe production line

Specification of Round Pipe Mill: φ89

The pipe production mill is φ89， specially designed to manufacture of round pipe of Φ25mm-Φ89mm with thickness of 1.0mm-4.0mm from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.
Finished product will be of round, square or rectangular pipe.

Process of Round Pipe Mill
{Steel strip}→→ Double-head un-coiler →→Shear and welder→→Horizontal accumulator→→Forming mill→→HF solid state welding→→Cooling→→Burr removing→→Sizing and Turks head→→Cutting saw →→ Run-out table
Basic conditions of Round Pipe Mill:
1. Pipe diameter: Φ25mm-Φ89mm
    Pipe Thickness: 1.0- 4.0mm
2. Square Pipe: 20X20mm - 80X80mm
    Rectangle Pipe: 20X30mm –40X80mm

   Pipe Thickness: 1.0– 3.5mm
3. Pipe Length: 4-12m
4. Length Tolerance: 0-6mm
5  Line speed: 30-80m/min

SteelTape Specification

1.Material:    Low Carbon steel (δb≤500Mpa, δs≤235Mpa)

2. SteelTape:

Inner diameter:Φ470-Φ510mm

Outer diameter: Φmax=1500mm

Strip steel width: 100mm-280mm

Strip steel thickness: 0.8mm-3.0mm

The maximum weight: 3.0 tons
