HG60 Tube Mill

Product Name: HG60 Tube Mill

Main Description:

The tube mill is intended for manufacturing of round pipe of Φ21mm-Φ63mm with thickness of 0.6mm– 3.0mm from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.

Finished product will be of round, square or rectangular pipe.

The manufacturing process provides for the uses of coiled strip precut in required width sizes in slitting machine.

Annual output:  20,000 ton, according to the yearly working days、daily working hours and the products.

Line speed:  30-100m/min

Feeding Direction:Right to left

The technical flow of the production line

{SteelTape}→→ Double-head un-coiler →→Strip-head Cutter and welder→→Cage Loop →→Forming section（Flattening unit +Main driving unit +Forming unit +Guide unit +High frequency induction welding unit +squeeze roller）+ De-burr frame →→Cooling unit →→ Sizing unit and straightener →→Flying saw under computer-control →→ Run-out table

We can offer extra rollers as spare parts.
